ความคิดเห็นที่ 107
ตอบคุณ ss2498 พอดีผมไม่ได้เข้ากระทู้หลายวัน ครับ คุณTon99 ได้ลอก เอกสารที่ผมเคยตั้งกระทู้เกี่ยวกับค่าความร้อน แต่ไม่มีใครให้ความกระจ่าง ค่าความร้อนดังกล่าวผมลอกมาจาก หน่วยงานที่เรียกว่า Department of Information and Computing Sciences ของ Newzealand ขอลงข้อมูลบางส่วนให้ดูดังนี้ครับ
It should be noted that because oxygenates contain oxygen that can not provide energy, they will have significantly lower energy contents. They are added to provide octane, not energy. For an engine that can be optimised for oxygenates, more fuel is required to obtain the same power, but they can burn slightly more efficiently, thus the power ratio is not identical to the energy content ratio. They also require more energy to vaporise. Energy Content Heat of Vaporisation Oxygen Content Nett MJ/kg MJ/kg wt% Methanol 19.95 1.154 49.9 Ethanol 26.68 0.913 34.7 MTBE 35.18 0.322 18.2 ETBE 36.29 0.310 15.7 TAME 36.28 0.323 15.7 Gasoline 42 - 44 0.297 0.0
Typical values for commercial fuels in megajoules/kilogram are [37]:- Gross Nett Hydrogen 141.9 120.0 Carbon to Carbon monoxide 10.2 - Carbon to Carbon dioxide 32.8 - Sulfur to sulfur dioxide 9.16 - Natural Gas 53.1 48.0 Liquified petroleum gas 49.8 46.1 Aviation gasoline 46.0 44.0 Automotive gasoline 45.8 43.8 Kerosine 46.3 43.3 Diesel 45.3 42.5 Obviously, for automobiles, the nett calorific value is appropriate, as the water is emitted as vapour. The engine can not utilise the additional energy available when the steam is condensed back to water. The calorific value is the maximum energy that can be obtained from the fuel by combustion, but the reality of modern SI engines is that thermal efficiencies of only 20-40% may be obtained, this limit being due to engineering and material constraints that prevent optimum thermal conditions being used. CI engines can achieve higher thermal efficiencies, usually over a wider operating range as well. Note that combustion efficiencies are high, it is the thermal efficiency of the engine is low due to losses. For a water-cooled SI engine with 25% useful work at the crankshaft, the losses may consist of 35% (coolant), 33% (exhaust), and 12% (surroundings)
จากคุณ :
amt (amt)
- [
24 มิ.ย. 48 12:23:13
]
|
|
|
